G4VSIntegration Class Reference

#include <G4VSIntegration.hh>

Inheritance diagram for G4VSIntegration:

Public Member Functions
	G4VSIntegration ()=default
virtual	~G4VSIntegration ()=default
virtual G4double	ProbabilityDensityFunction (G4double)=0
virtual const G4String &	ModelName () const
void	InitialiseIntegrator (G4double accuracy, G4double fact1, G4double fact2, G4double de, G4double dmin, G4double dmax)
G4double	ComputeIntegral (const G4double emin, const G4double emax)
G4double	SampleValue ()
	G4VSIntegration (const G4VSIntegration &)=delete
G4VSIntegration &	operator= (const G4VSIntegration &)=delete
G4bool	operator== (const G4VSIntegration &right) const =delete
G4bool	operator!= (const G4VSIntegration &right) const =delete
void	SetVerbose (G4int verb)

Detailed Description

Definition at line 46 of file G4VSIntegration.hh.

Constructor & Destructor Documentation

G4VSIntegration() [1/2]

G4VSIntegration::G4VSIntegration ( )

default

Referenced by G4VSIntegration(), operator!=(), operator=(), and operator==().

~G4VSIntegration()

virtual G4VSIntegration::~G4VSIntegration ( )

virtualdefault

G4VSIntegration() [2/2]

G4VSIntegration::G4VSIntegration ( const G4VSIntegration & )

delete

Member Function Documentation

ComputeIntegral()

G4double G4VSIntegration::ComputeIntegral	(	const G4double	emin,
		const G4double	emax )

Definition at line 54 of file G4VSIntegration.cc.

{
  G4double res = 0.0;
  if (emin >= emax) { return res; }
  fEmin = emin;
  fEmax = emax;

  // preparing smart binning
  G4int nbin = G4lrint((emax - emin)/fDelta) + 1;
  nbin = std::max(nbin, 6);
  G4double edelta = (emax - emin)/static_cast<G4double>(nbin);
  nbin += nbin;

  // prepare integration
  G4double x(emin), y(0.0);
  fPmax = ProbabilityDensityFunction(x);
  G4double problast = fPmax;
#ifdef G4VERBOSE
  if (fVerbose > 1) {
    G4cout << "### G4VSIntegration::ComputeIntegral: "
           << "Pmax=" << fPmax << " Emin=" << emin
           << " Emax=" << emax << " dE=" << edelta << " nbin=" << nbin
           << G4endl;
  }
#endif

  fE1 = fE2 = emax;
  fP1 = fP2 = 0.0;
  G4bool endpoint = false;
  x += edelta;
  for (G4int i=0; i<=nbin; ++i) {
    // the last point - may be earlier due to dynamic interval
    if (x >= emax) {
      edelta += emax - x;
      x = emax;
      endpoint = true;
    }
    y = ProbabilityDensityFunction(x);
#ifdef G4VERBOSE
    if (fVerbose > 2) {
      G4cout << "    " << i << ".  E=" << x << "  prob=" << y
             << " Edel=" << edelta << G4endl;
    }
#endif
    if (y >= fPmax) {
      fPmax = y;
      // for the case of 2nd maximum
      fP1 = fP2 = 0.0;
      fE1 = fE2 = emax;
    } else if (!endpoint) {
      if (0.0 == fP1) {
    // definition of the 2nd area
        if (y < fFactor1*fPmax) {
          fE1 = x;
          fP1 = y;
        }
      // for the case of 2nd maximum in the 2nd area
      // shifted energy limit between the 1st and 2nd areas
      } else if (y > fP1) {
    fP2 = 0.0;
    fE1 = x;
    fP1 = y;
    fE2 = emax;
    // definition of the 3d area
      } else if (0.0 == fP2 && y < fFactor1*fP1) {
        fE2 = x;
        fP2 = y;
    // extra maximum inside the 3d area
        // shifted energy limit between the 2nd and 3d areas
      } else if (0.0 < fP2 && y > fP2) {
    if (y > fP1) { fP1 = y; }
    fE2 = x;
    fP2 = y;
      }
    }

    G4double del = (y + problast)*edelta*0.5;
    res += del;

    // end of the loop condition
    if ((del < fAcc*res && 0 < fP2) || endpoint) { break; }
    problast = y;

    // smart next step definition
    if (del != res) {
      if (del > 0.8*res && 0.7*edelta > fMinDelta) {
    edelta *= 0.7;
      } else if (del < 0.1*res && 1.5*edelta < fMaxDelta) {
    edelta *= 1.5;
      }
    }
    x += edelta;
  }
#ifdef G4VERBOSE
  if (fVerbose > 1) {
    G4cout << "### G4VSIntegration::ComputeIntegral: "
           << "I=" << res << " E1=" << fE1 << " E2=" << fE2
           << " Pmax=" << fPmax << " P1=" << fP1 << " P2=" << fP2
           << G4endl;
  }
#endif
  return res;
}

Referenced by G4VPreCompoundFragment::CalcEmissionProbability(), G4GEMChannelVI::EmittedFragment(), G4GEMChannelVI::GetEmissionProbability(), and G4VEmissionProbability::IntegrateProbability().

InitialiseIntegrator()

void G4VSIntegration::InitialiseIntegrator	(	G4double	accuracy,
		G4double	fact1,
		G4double	fact2,
		G4double	de,
		G4double	dmin,
		G4double	dmax )

Definition at line 36 of file G4VSIntegration.cc.

{
  if (acc > 0.0) { fAcc = acc; }
  if (f1 > 0.0 && f1 < 1.0) { fFactor1 = f1; }
  if (f2 > 1.0 && f2 < 5.0) { fFactor2 = f2; }
  if (de > 0.0) { fDelta = de; }
  fMinDelta = (dmin <= de && dmin > 0.0) ? dmin : de;
  fMaxDelta = (dmax > de) ? dmax : de;
  if (fVerbose > 2) {
    G4cout << "### G4VSIntegration::InitialiseIntegrator: "
           << "fAcc=" << fAcc << " fFact1=" << fFactor1
       << " fFact2=" << fFactor2 << " dE=" << fDelta
       << " dEmin=" << fMinDelta << " dEmax=" << fMaxDelta << G4endl;
  }
}

Referenced by G4GEMChannelVI::G4GEMChannelVI(), G4VPreCompoundFragment::G4VPreCompoundFragment(), G4DNABornIonisationModel::Initialise(), G4DNARuddIonisationDynamicModel::Initialise(), and G4VEmissionProbability::ResetIntegrator().

ModelName()

const G4String & G4VSIntegration::ModelName ( ) const

virtual

Reimplemented in G4GEMChannelVI.

Definition at line 265 of file G4VSIntegration.cc.

{
  return dummy;
}

Referenced by SampleValue().

operator!=()

G4bool G4VSIntegration::operator!= ( const G4VSIntegration & right ) const

delete

operator=()

G4VSIntegration & G4VSIntegration::operator= ( const G4VSIntegration & )

delete

operator==()

G4bool G4VSIntegration::operator== ( const G4VSIntegration & right ) const

delete

ProbabilityDensityFunction()

virtual G4double G4VSIntegration::ProbabilityDensityFunction ( G4double )

pure virtual

Implemented in G4DNABornIonisationModel, G4DNARuddIonisationDynamicModel, G4GEMChannelVI, G4VEmissionProbability, and G4VPreCompoundFragment.

Referenced by ComputeIntegral(), and SampleValue().

SampleValue()

G4double G4VSIntegration::SampleValue

(

)

Definition at line 158 of file G4VSIntegration.cc.

{
  // should never happen
  if (fEmin >= fEmax) { return fEmin; }

  // if 3d region is considered it is subdivided on 2 parts
  // so sampling may be performed in 4 energy intervals
  G4double p3 = 0.0;
  G4double p4 = 0.0;
  G4double E3 = fEmax;
  G4double Q0 = fPmax*fFactor2;
  G4double Q1 = fP1*fFactor2;
  G4double Q2 = fP2*fFactor2;
  G4double Q3 = 0.0;

  // for some distributions it may happens that there is a local maximum
  // closed to maximal energy
  G4double Q4 = ProbabilityDensityFunction(fEmax - 0.02*(fEmax - fEmin))*fFactor2;
  Q0 = std::max(Q0, Q4);
  if (Q1 > 0.0) { Q1 = std::max(Q1, Q4); }

  // integral under the 1st and the 2nd areas
  G4double p1 = (fE1 - fEmin)*Q0;
  G4double p2 = (fE2 - fE1)*Q1;

  // if p2 is very small the 2nd area should not be considered
  if (p2 < 1.e-8*p1) {
    p2 = 0.0;
    p1 = (fE2 - fEmin)*Q0;
    fE1 = fE2;
  }

  // 3d area may be considered
  if (Q2 > 0.0 && fE2 < fEmax) {
    E3 = fEmax - 0.5*(fEmax - fE2);
    Q3 = ProbabilityDensityFunction(E3)*fFactor2;
    Q2 = std::max(Q2, Q3);
    Q3 = std::max(Q3, Q4);
    p3 = (E3 - fE2)*Q2;
    p4 = (fEmax - E3)*Q3;
  }
  // sampling in 4 areas, probabilities may be zero except p1
  G4double sum = p1 + p2 + p3 + p4;
  G4double del1 = (fE1 - fEmin)/p1;
  G4double del2 = (p2 > 0.0) ? (fE2 - fE1)/p2 : 0.0;
  G4double del3 = (p3 > 0.0) ? (E3 - fE2)/p3 : 0.0;
  G4double del4 = (p4 > 0.0) ? (fEmax - E3)/p4 : 0.0;

  CLHEP::HepRandomEngine* rndm = G4Random::getTheEngine();
  const G4int nmax = 100000;
  G4double e, gmax, gg;
  for (G4int n=0; n < nmax; ++n) {
    G4double q = rndm->flat();
    G4double p = sum*q;
    G4int idx = 0;
    if (p <= p1) {
      gmax = Q0;
      e = del1*p + fEmin;
    } else if (p <= p1 + p2) {
      gmax = Q1;
      e = del2*(p - p1) + fE1;
      idx = 1;
    } else if (p <= p1 + p2 + p3) {
      gmax = Q2;
      e = del3*(p - p1 - p2) + fE2;
      idx = 2;
    } else {
      gmax = Q3;
      e = del4*(p - p1 - p2 - p3) + E3;
      idx = 3;
    }
    gg = ProbabilityDensityFunction(e);
    if ((gg > gmax || n >= nmax) && fVerbose > 0) {
      ++fnWarn;
      if (fnWarn < fWarnLimit) {
    G4cout << "### G4VSIntegration::SampleValue() for " << ModelName()
           << " in area=" << idx << " n=" << n << " gg/gmax=" << gg/gmax
           << " prob=" << gg << " gmax=" << gmax << G4endl;
    G4cout << "    E=" << e << " Emin=" << fEmin << " Emax=" << fEmax
           << " E1=" << fE1 << " E2=" << fE2 << " E3=" << E3
           << " F0=" << Q0 << " F1=" << Q1 << " F2=" << Q2 << " F3=" << Q3
           << " F4=" << Q4 << G4endl;
      }
    }
    if (gmax*rndm->flat() <= gg) {
#ifdef G4VERBOSE
      if (fVerbose > 1) {
    G4cout << "### G4VSIntegration::SampleValue for " << ModelName()
           << " E=" << e << " Ntry=" << n
           << " Emin=" << fEmin << " Emax=" << fEmax << G4endl;
      }
#endif
      return e;
    }
  }
  // if sampling not converged, then sample uniformaly in the 1st energy region
  e = fEmin + rndm->flat()*(fE1 - fEmin);
#ifdef G4VERBOSE
  if (fVerbose > 1) {
    G4cout << "### G4VSIntegration::SampleValue for " << ModelName()
           << " E=" << e << " Ntry=" << nmax
           << " Emin=" << fEmin << " Emax=" << fEmax << G4endl;
  }
#endif
  return e;
}

Referenced by G4GEMChannelVI::EmittedFragment(), G4VEmissionProbability::SampleEnergy(), and G4VPreCompoundFragment::SampleKineticEnergy().

SetVerbose()

void G4VSIntegration::SetVerbose ( G4int verb )

inline

Definition at line 80 of file G4VSIntegration.hh.

{ fVerbose = verb; }

---

The documentation for this class was generated from the following files:

• G4VSIntegration.hh
• G4VSIntegration.cc
